4K Videos.
\n
Mavic Air 2 lets you shoot 4K/60fps videos. Being able to shoot 4K content means you get high-quality content. The level of clarity, brightness, and detail is top of the line. And if you’re afraid of the file size, Mavic Air 2 uses HEVC (H.265) video codec that lets you record using less storage but still retain the same quality.
\n
HDR Videos.
\n
Mavic Air 2 comes with HDR by default. Mavic Air 2 comes with a Quad Bayer image sensor that lets you shoot high-quality images. With HDR, you get darker blacks and brighter whites which increases the vividness of the image.
\n
48MP Photos.
\n
Mavic Air 2 lets you shoot 48MP photos. The larger the camera lens, the more detailed an image is. With a detailed image, you can zoom in and pick out details or crop the images multiple times without losing quality.
\n
SmartPhoto Optimized Capture.
\n
Mavic Air 2 comes with SmartPhoto. With SmartPhoto, you get scene recognition, hyperlight, and HDR combined. You get scene optimization that improves image quality.
\n
8K Hyperlapse Time and Movement.
\n
Mavic Air 2 comes with support for Hyperlapse 8K. With 8K Hyperlapse, you get to warp time and space for amazing footage. You can take Hyperlapse 8K without any complicated post-processing.
\n
Long Battery Life.
\n
Mavic Air 2 comes with long battery life. With a max speed of 68 kph, you get to fly your Mavic Air 2 for longer and take amazing photos. And with Obstacle Avoidance, you get to fly safer without any issues.
\n
Mavic Air 2 Specifications.
\n
Aircraft.
\n
\n-
Weight: 570 g
\n-
Size: Folded: 180×97×74 mm (Length×Width×Height)
\nUnfolded: 183×253×77 mm (Length×Width×Height)
\n-
Diagonal Distance: 302 mm
\n-
Max Ascent Speed: 4 m/s (S Mode); 4 m/s (N Mode)
\n-
Max Descent Speed: 3 m/s (S Mode); 3 m/s (N Mode); 5 m/s (S Mode during a sharp descent); 3 m/s (all modes at elevations over 4500 m)
\n-
Max Service Ceiling Above Sea Level: 5000 m
\n-
Max Flight Time (without wind): 34 minutes
\n-
Max Hover Time (without wind): 33 minutes
\n-
Max Flight Distance: 18.5 km
\n-
Max Horizontal Flight Speed: 19 m/s (S Mode); 12 m/s (N Mode); 5 m/s (T Mode)
\n-
Max Wind Resistance: 8.5-10.5 m/s (Level 5)
\n-
Max Tilt Angle: 35° (S Mode); 20° (N Mode); 35° (N Mode under strong wind)
\n-
Max Angular Velocity: 250°/s (S Mode); 250°/s (N Mode)
\n-
Operating Temperature Range: -10° to 40°C (14° to 104°F)
\n-
Operating Frequency: 2.400-2.4835 GHz; 5.725-5.850 GHz
\n-
Transmitter Power (EIRP): 2.400-2.4835 GHz: FCC: ?26 dBm; CE: ?20 dBm; SRRC: ?20 dBm; MIC: ?20 dBm
\n5.725-5.850 GHz: FCC: ?26 dBm; CE: ?14 dBm; SRRC: ?26 dBm
\n-
Hovering Accuracy Range: Vertical: ±0.1 m (with vision positioning); ±0.5 m (with GPS positioning)
\nHorizontal: ±0.1 m (with vision positioning); ±1.5 m (with GPS positioning)
\n-
Propellers: Quick-release, low noise, folding
\n-
Satellite Systems: GPS+GLONASS
\n-
Compass: Single Compass
\n-
IMU: Single IMU
\n-
Internal Storage: 8 GB
\n
\n
Battery.
\n
\n-
Capacity: 3500 mAh
\n-
Voltage: 11.55 V
\n-
Charging Voltage Limit: 13.2 V
\n-
Battery Type: LiPo 3S
\n-
Energy: 40.42 Wh
\n-
Weight: 198 g
\n-
Charging Temperature: 5° to 40°C (41° to 104°F)
\n-
Max Charging Power: 38 W
\n
\n
Camera.
\n
\n-
Sensor: 1/2? CMOS
\nEffective Pixels: 12 MP and 48 MP
\n-
Lens: FOV: 84°
\nEquivalent Focal Length: 24 mm
\nAperture: f/2.8
\nFocus Range: 1 m to ?
\n-
ISO: Video: 100-6400
\nPhoto (12 MP): 100-3200 (Auto); 100-6400 (Manual)
\nPhoto (48 MP): 100-1600 (Auto); 100-3200 (Manual)
\n-
Max Photo Resolution: 48 MP 8000×6000 pixel
\n-
Photo Modes: Single: 12 MP and 48 MP
\nBurst: 12 MP, 3/5/7 frames
\nAutomatic Exposure Bracketing (AEB): 12MP, 3/5 Frames at 0.7EV Bias
\nTimed: 12 MP 2/3/5/7/10/15/20/30/60 seconds
\nSmartPhoto: Scene Recognition, HyperLight, and HDR
\nHDR Panorama: Vertical (3×1): 3328×8000 pixels (Width×Height); Wide (3×3): 8000×6144 pixels (Width×Height); 180° Panorama (3×7): 8192×3500 pixels (Width×Height); Sphere (3×8+1): 8192×4096 pixels (Width×Height)
\n-
Photo Formats: JPEG/DNG (RAW)
\n-
Video Resolution and Frame Rates: 4K Ultra HD: 3840×2160 24/25/30/48/50/60 fps
\n2.7K: 2688×1512 24/25/30/48/50/60 fps
\nFHD: 1920×1080 24/25/30/48/50/60/120/240 fps
\n4K Ultra HD HDR: 3840×2160 24/25/30 fps
\n2.7K HDR: 2688×1512 24/25/30 fps
\nFHD HDR: 1920×1080 24/25/30 fps
\n-
Color Profiles: D-Cinelike, Normal
\n-
Video Formats: MP4/MOV (H.264/MPEG-4 AVC, H.265/HEVC)
\n-
Max Bitrate: 120 Mbps
\n-
Supported SD Cards: Supports a microSD with a capacity of up to 256 GB
\n-
Supported File Systems: FAT32 and exFAT
\n-
Zoom: Not available
\n
\n
Gimbal.
\n
\n-
Stabilization: 3-axis (tilt, roll, pan)
\n-
Mechanical Range: Tilt: -135° to 45°
\nRoll: -45° to 45°
\nPan: -100° to 100°
\n-
Controllable Range: Tilt: -90° to 0° (Default)
\n-90° to 24° (Extended)
\n-
Max Controllable Speed (tilt): 100°/s
\n-
Angular Vibration Range: ±0.01°
\n
\n
Vision System.
\n
\n-
Forward: Precision Measurement Range: 0.35-22.0 m
\nDetection Range: 0.35 to 44 m
\nEffective Sensing Speed: 12 m/s
\nField of View (FOV): 71° (horizontal), 56° (vertical)
\n-
Backward: Precision Measurement Range: 0.37-23.6 m
\nDetection Range: 0.37-47.2 m
\nEffective Sensing Speed: 12 m/s
\nField of View (FOV):
\n44° (horizontal), 57° (vertical)
\n-
Available Downward Sensors: Dual Vision Sensors + Time of Flight Sensors (ToF)
\n-
Downward: ToF Measurement Range: 0.1-8 m
\nHovering Range: 0.5-30 m
\nVision Sensor Hovering Range: 0.5-60 m
\n-
Left/Right: None
\n-
Downward Auxillary Light: Single LED
\n- Safety.
\n-
Obstacle Avoidance System: Advanced Pilot Assistance Systems (APAS) 3.0
\n
\n
Video Transmission.
\n
\n-
Transmission System: OcuSync 2.0; 2.4 GHz/5.8 GHz Auto-Switching
\n-
Max Transmission Distance: 10 km (FCC), 6 km (CE), 6 km (SRRC), 6 km (MIC)
\n-
Live View Quality: 720p@30fps/1080@p30fps
\n-
Latency (depending on environmental conditions and mobile device): 120-130 ms
\n-
Video Transmission Encoding format: H.265/H.264 (Auto-switches depending on encoding capabilities of device)
\n-
Max Transmission Bitrate: 12 Mbps
\n-
Operating Frequency: 2.400-2.4835 GHz; 5.725-5.850 GHz
\n
\n
Remote Controller.
\n
\n-
Remote Controller Transmission System: OcuSync 2.0
\n-
Supported Mobile Device Connectors: Lightning, Micro USB, USB Type-C
\n180×86×10 mm (Height×Width×Thickness)
\n-
Operating Temperature: -10° to 40°C (14° to 104°F)
\n-
Transmitter Power (EIRP):
\n2.400-2.4835 GHz: FCC: ?26 dBm; CE: ?20 dBm; SRRC: ?20 dBm; MIC: ?20 dBm
\n5.725-5.850 GHz: FCC: ?26 dBm; CE: ?14 dBm; SRRC: ?26 dBm
\n-
Operating Current/Voltage: 1200 mA@3.7V (Android)
\n700 mA@ 3.7 V (iOS)
\n
\n
Charger.
\n
\n-
Charging Input: 100-240 V, 50/60 Hz, 1.3 A
\n-
Charging Output: Charging Port: 13.2 V?2.82 A
\nUSB Port: 5 V?2 A
\n-
Voltage: 13.2 V
\n-
Rated Power: 38 W
\n
\n
SD Cards.
\n
\n-
Supported SD Cards: Micro SD™
\nSupports a microSD card with a capacity of up to 256 GB.
\nA UHS-I Speed Grade 3 rating microSD card is require
